Characteristics:
It with small frame, but open mold exactly and no counteractive. No lock load, apply to low pressure lock molding. It's action irrespective of compound molding sequence. Locking blocks have back function when hot runner plate close before devide face.
| Type | Slide seat - Cam seat panel pin gasket | |||||||||||||||||||||
| A | A1 | A2 | A3 | A4 | B | B1 | B2 | C | C1 | C2 | W | U | Bolt hole M | d | t | W1 | W2 | T | L | ST | SL | |
| PPLS (For light load) |
68 | 61.5 | 55 | 19 | 7 | 26 | 19 | 7 | 24 | 17 | 7 | 20 | 8 | M6 | ￠6 | 6 | 13 | 5.9 | 7 | 250 | 6.5 | 40 |
| PPLM (For medium load) |
88 | 79 | 70 | 24 | 9 | 38 | 29 | 9 | 30 | 21 | 9 | 30 | 12 | M8 | ￠8 | 7 | 16 | 8 | 10 | 300 | 8 | 50 |
| PPLL (For heavy load) |
104 | 93 | 82 | 27 | 11 | 48 | 37 | 11 | 38 | 27 | 11 | 45 | 20 | M10 | ￠10 | 8 | 20 | 9.5 | 15.5 | 350 | 10.2 | 55 |
Order example for first item(Type No. x Pcs): PPLSx10
